| Intel® VT-x with Extended Page Tables (EPT) | Ja | ||
| Intel® 64 | Ja | ||
| Intel® Virtualization Technology (VT-x) | Ja | ||
| Intel® Trusted Execution Technology | Ja | ||
| Intel® AES New Instructions (Intel® AES-NI) | Ja | ||
| Intel® Turbo Boost Technology | 2.0 | ||
| Intel® TSX-NI | Ja | ||
| Intel® Hyper Threading Technology (Intel® HT Technology) | Ja | ||
| Enhanced Intel SpeedStep Technology | Ja | ||
| Intel® Virtualization Technology for Directed I/O (VT-d) | Ja | ||
| Kleur van het product | Zwart | ||
| Rack-montage | Ja | ||
| Type behuizing | Rack (4U) | ||
| Maximaal aantal PCI Express-lijnen | 48 | ||
| Processor operating modes | 64-bit | ||
| Codenaam processor | Cascade Lake | ||
| Processor aantal threads | 16 | ||
| Processor lithografie | 14 nm | ||
| Processor socket | LGA 3647 | ||
| Processorfamilie | Intel® Xeon® Silver | ||
| Processormodel | 4208 | ||
| Aantal processorkernen | 8 | ||
| Aantal geïnstalleerde processoren | 1 | ||
| Processorfabrikant | Intel | ||
| Maximale turbofrequentie van processor | 3,2 GHz | ||
| Frequentie van processor | 2,1 GHz | ||
| Processor cache | 11 MB | ||
| Hot-plug ondersteuning | Ja | ||
| Compatibele besturingssystemen | Microsoft Windows Server 2016/2012 R2\nRed Hat Enterprise Linux 6/7 x64\nLinux Enterprise Server 12 SP2/11 SP4\nVMware vSphere (ESXi) 6.5/6.0 U3 | ||
| Prestatiebeheer | XClarity Advanced | ||
| Execute Disable Bit | Ja | ||
| Ondersteunde instructie sets | AVX-512 | ||
| Schaalbaarheid | 2S | ||
| Ingebouwde opties beschikbaar | Nee | ||
| Redundante voeding | Ja | ||
| Netvoeding | 550 W | ||
| Thermal Design Power (TDP) | 85 W | ||
| Soorten RAID | 0,1,5,6,10,50,60 | ||
| Hot-swap | Ja | ||
| Trusted Platform Module (TPM) | Ja | ||
| Trusted Platform Module (TPM) version | 1.2 | ||
| Ondersteunde RAID-controllers | 930-8i | ||
| HDD omvang | 2.5" | ||
| HDD interface | SATA, Serial Attached SCSI (SAS) | ||
| Ondersteunde HDD-groottes | 2.5" | ||
| RAID support | Ja | ||
| Aantal USB 2.0-poorten | 5 | ||
| VGA (D-Sub)poort(en) | 1 | ||
| Aantal Ethernet LAN (RJ-45)-poorten | 2 | ||
| On-board graphics adapter model | Niet beschikbaar | ||
| Ingebouwde grafische adapter | Ja | ||
| Geheugenlayout | 1 x 16 GB | ||
| Kloksnelheid geheugen | 2666 MHz | ||
| Intern geheugen | 16 GB | ||
| Intern geheugentype | DDR4-SDRAM | ||
| Geheugenslots | 12 | ||
| Ethernet LAN | Ja | ||
| Bekabelingstechnologie | 10/100/1000Base-T(X) | ||
| Ethernet interface type | Gigabit Ethernet | ||
| Breedte | 176 mm | ||
| Diepte | 670 mm | ||
| Hoogte | 438 mm | ||
