| Intel® VT-x with Extended Page Tables (EPT) | Ja | ||
| Intel® Clear Video-technologie | Ja | ||
| Intel® 64 | Ja | ||
| Intel® Virtualization Technology (VT-x) | Ja | ||
| Intel® Trusted Execution Technology | Ja | ||
| Intel® AES New Instructions (Intel® AES-NI) | Ja | ||
| Intel® Turbo Boost Technology | 2.0 | ||
| Intel® Quick Sync Video Technology | Ja | ||
| Intel® InTru™ 3D Technology | Ja | ||
| Intel® Clear Video HD Technology (Intel® CVT HD) | Ja | ||
| Intel® Secure Key | Ja | ||
| Intel® TSX-NI | Ja | ||
| Intel® OS Guard | Ja | ||
| Intel® Software Guard Extensions (Intel® SGX) | Ja | ||
| Intel® Hyper Threading Technology (Intel® HT Technology) | Ja | ||
| Enhanced Intel SpeedStep Technology | Ja | ||
| Intel® Virtualization Technology for Directed I/O (VT-d) | Ja | ||
| Kleur van het product | Zwart | ||
| Rack-montage | Ja | ||
| Type behuizing | Rack (1U) | ||
| Rekrails | Ja | ||
| Maximaal aantal PCI Express-lijnen | 16 | ||
| Klokgeheugen-snelheden ondersteund door processor | 2666 MHz | ||
| Processor operating modes | 64-bit | ||
| Codenaam processor | Coffee Lake | ||
| Maximaal intern geheugen ondersteund door processor | 128 GB | ||
| Geheugentypen ondersteund door processor | DDR4-SDRAM | ||
| Processor aantal threads | 12 | ||
| Tjunction | 100 °C | ||
| Processor lithografie | 14 nm | ||
| Max. aantal SMP-processoren | 1 | ||
| Chipset moederbord | Intel C246 | ||
| Processor socket | LGA 1151 (Socket H4) | ||
| Processorfamilie | Intel Xeon E | ||
| Processormodel | E-2276G | ||
| Aantal processorkernen | 6 | ||
| Aantal geïnstalleerde processoren | 1 | ||
| Processorfabrikant | Intel | ||
| Maximale turbofrequentie van processor | 4,9 GHz | ||
| Frequentie van processor | 3,8 GHz | ||
| Processor cache | 12 MB | ||
| PCI Express configuraties | 1x16,2x8,1x8+2x4 | ||
| PCI Express slots versie | 3.0 | ||
| PCI Express x4 (Gen 3.x) slots | 1 | ||
| PCI Express x8 (Gen 3.x) slots | 2 | ||
| CPU configuratie (max) | 1 | ||
| Compatibele besturingssystemen | Microsoft Windows Server 2016/2019, Red Hat Enterprise Linux 7/8, SUSE Linux Enterprise Server 12/15, VMware vSphere (ESXi) 6.5/6.7/7.0 | ||
| Prestatiebeheer | XClarity Standard | ||
| Interne drive bays | 8 | ||
| Execute Disable Bit | Ja | ||
| Idle States | Ja | ||
| Thermal Monitoring Technologies | Ja | ||
| Ondersteunde instructie sets | SSE4.1,SSE4.2,AVX 2.0 | ||
| Schaalbaarheid | 1S | ||
| Ingebouwde opties beschikbaar | Nee | ||
| Aantal hoofdvoedingen | 1 | ||
| Aantal ondersteunde redundante voedingen | 2 | ||
| Redundante voeding | Ja | ||
| Netvoeding | 450 W | ||
| Thermal Design Power (TDP) | 80 W | ||
| Soorten RAID | 0,1,5,10 | ||
| Hot-swap | Ja | ||
| Trusted Platform Module (TPM) | Ja | ||
| Trusted Platform Module (TPM) version | 2.0 | ||
| HDD omvang | 2.5" | ||
| HDD interface | SATA III, Serial Attached SCSI (SAS) | ||
| Ondersteunde HDD-groottes | 2.5" | ||
| SSD interfaces | NVMe, NVMe 3.0, PCI Express 3.0, SATA III | ||
| Maximale opslagcapaciteit | 24 TB | ||
| RAID support | Ja | ||
| Aantal poorten USB 3.2 Gen 2 (3.1 Gen 2) Type A | 2 | ||
| Aantal USB 2.0-poorten | 1 | ||
| Seriële poort(en) | 1 | ||
| VGA (D-Sub)poort(en) | 2 | ||
| Aantal Ethernet LAN (RJ-45)-poorten | 3 | ||
| On-board grafische adapter ID | 0x3E96 | ||
| Aantal displays ondersteund (door on-board grafische adapter) | 3 | ||
| On-board graphics adapter model | Intel UHD Graphics P630 | ||
| Basisfrequentie ingebouwde grafische adapter | 350 MHz | ||
| Graphics on-board -adapter dynamische frequentie (max) | 1200 MHz | ||
| Maximaal geheugen ingebouwde grafische adapter | 128 GB | ||
| Maximum geheugen grafische adapter | 16 MB | ||
| Ingebouwde grafische adapter | Ja | ||
| Geheugenlayout | 1 x 16 GB | ||
| Kloksnelheid geheugen | 2666 MHz | ||
| Intern geheugen | 16 GB | ||
| Intern geheugentype | DDR4-SDRAM | ||
| Maximum intern geheugen | 128 GB | ||
| Geheugenslots | 4 x DIMM | ||
| ECC | Ja | ||
| Ethernet LAN | Ja | ||
| Bekabelingstechnologie | 10/100/1000Base-T(X) | ||
| LAN controller | Broadcom BCM5720 | ||
| Ethernet interface type | Gigabit Ethernet | ||
| Gewicht | 9,1 kg | ||
| Breedte | 434 mm | ||
| Diepte | 498 mm | ||
| Hoogte | 43 mm | ||
