| Spanning tree protocol | Ja | ||
| Jumbo Frames ondersteuning | Ja | ||
| IGMP snooping | Ja | ||
| Netwerkstandaard | IEEE 802.1ab,IEEE 802.1D,IEEE 802.1p,IEEE 802.1Q,IEEE 802.1s,IEEE 802.1v,IEEE 802.1w,IEEE 802.1x,IEEE 802.2,IEEE 802.3,IEEE 802.3ab,IEEE 802.3ac,IEEE 802.3ad,IEEE 802.3i,IEEE 802.3u,IEEE 802.3x,IEEE 802.3z | ||
| Auto MDI/MDI-X | Ja | ||
| 10G support | Nee | ||
| VLAN=ondersteuning | Ja | ||
| Datastroombeheer | Ja | ||
| Verbindingsaggregatie | Ja | ||
| Broadcast stormbeheer | Ja | ||
| Vermogensverbruik (max) | 37 W | ||
| Power over Ethernet (PoE) | Ja | ||
| Uitgangsvermogen | 450 W | ||
| DHCP-functies | DHCP server,DHCP client | ||
| Statische poort beveiliging | Ja | ||
| Access Control List (ACL) | Ja | ||
| System event log | Ja | ||
| Aantal basis-switching RJ-45 Ethernet-poorten | 24 | ||
| Type basis-switching RJ-45 Ethernet-poorten | Gigabit Ethernet (10/100/1000) | ||
| Aantal moduleslots SPF | 2 | ||
| Switchingcapaciteit | 52 Gbit/s | ||
| Aantal VLANs | 4096 | ||
| Aantal wachtrijen | 4 | ||
| Throughput | 38,7 Mpps | ||
| MAC-adrestabel | 16000 entries | ||
| Vormfactor | 1U | ||
| Rack-montage | Ja | ||
| Kleur van het product | Zwart | ||
| Ondersteunde netwerkprotocollen | IPv4, IPv6, HTTP, TCP, IP, ICMP, TFTP, BOOTP, UDP, ARP, GARP, GMP, LLDP, RMON, MSTP, UDLD, TLS, PPP, Telnet | ||
| Beheerprotocollen | SNMPv1, SNMPv2, SNMPv3, SMIv1, SMIv2, IGMPv1, IGMPv2, IGMPv3 | ||
| MIB-ondersteuning | Y | ||
| Switch type | Managed | ||
| Web-gebaseerd management | Ja | ||
| Multicast-ondersteuning | Ja | ||
| Quality of Service (QoS) | Ja | ||
| Switch-laag | L2+ | ||
| Gewicht | 3,8 kg | ||
| Breedte | 209 mm | ||
| Diepte | 450 mm | ||
| Hoogte | 41,2 mm | ||
| Totaal Power over Ethernet (PoE)-budget | 370 W | ||
| Aantal Power over Ethernet plus (PoE +)-poorten | 12 | ||
| Hoeveelheid Power over Ethernet (PoE) ports | 12 | ||
| Temperatuur, in bedrijf | 0 - 45 °C | ||
| Temperatuur bij opslag | -20 - 70 °C | ||
| Relatieve luchtvochtigheid, in bedrijf | 10 - 90 procent | ||
| Luchtvochtigheid bij opslag | 10 - 80 procent | ||
| Warmtedissipatie | 126,3 BTU/h | ||
| Stapelbaar | Nee | ||
| Upgraden van firmware mogelijk | Ja | ||
| Geluidsniveau | 55,3 dB | ||
